Cherry Master ED-11 Update Kit Set By Corsica
Product ID: 00026
CHERRY MASTER ED-11
NOW YOU CAN UPDATE YOUR PCB
This Sub - PCB Is Plug And Play
This Version Is With "Hold A Pair" Back To Back
With "Fruit Bonus" And "Pinch Take" Function!
The kit installs in seconds!
No soldering or special skills needed.
No special wiring or switches are needed!
Easy To Install (Info For Old PCB Above):
1. Test The Cherry Master Board, Make Sure It Works.
2. Unplug The Z80 CPU From GH-16 (U80).
3. Plug In The Cherry Master Update Sub-Board Into The CPU Socket.
1. Test The Cherry Master Board, Make Sure It Works.
2. Unplug The Z80 CPU From GH-16 (U80).
3. Plug In The Cherry Master Update Sub-Board Into The CPU Socket.
Beware Of The Direction Of The CPU's Notch.
The Notch On The CPU's Sub-board Should Be Facing The Same Direction As The One You Took Out.
The Notch On The CPU's Sub-board Should Be Facing The Same Direction As The One You Took Out.
You Can Also Uses The Sub-PCB On The New Type PCB As Shown Below
Easy To Install (Info For New PCB Above):
1. Test The Cherry Master Board, Make Sure It Works.
2. Unplug The Z80 CPU At N-1.
3. Plug In The Cherry Master Update Sub-Board Into The CPU Socket
Beware Of The Direction Of The CPU's Notch.
The Notch On The CPU's Sub-board Should Be Facing The Same Direction As The One You Took Out.
1. Test The Cherry Master Board, Make Sure It Works.
2. Unplug The Z80 CPU At N-1.
3. Plug In The Cherry Master Update Sub-Board Into The CPU Socket
Beware Of The Direction Of The CPU's Notch.
The Notch On The CPU's Sub-board Should Be Facing The Same Direction As The One You Took Out.
AVAILABLE THE BELOW FRUITS BONUS VERSIONS:
500 - 1000
1000 - 3000
2000 - 5000
3000 - 8000
5000 - 10000
10000 - 20000
20000 - 40000
20000 - 60000
30000 - 50000
30000 - 80000
50000 - 90000
